ATS-31, Double Acting

Mini Hydraulic Power Unit, Total Enclosure

Super slim, low profile size 93X93mm.

Aluminum housing with hard anodizing.

Total enclosure with IP68 protection grade

High tolerable to tough working conditions.

Oil immersed AC motor built-in.

Low noise level 60dB.

Rated Power 350W.








Functions

- Driving double acting hydraulic cylinderextending or retracting.

- Choose the appropriate pump sizeaccording to the load of your application.

- Port P and T, standard options:     1. M12X1.5,      2. SAE4#(7/16X20UNF).  For other port size, please consult us.

 - Available Motor Size

1.  Rated Power 350W, AC 220V,50Hz, Single Phase  ;   2. Rated Power 350W, AC 380V, 50Hz, Three Phase

 - Duty Cycle: Intermittent running, S2=30s, S3 15% ED.    It may be varies with loads , pleaseconsult us.

- Max Working pressure: 170Bar (2450PSI)

- Proof Pressure: 230 Bar (3335PSI)

Product features
Outline dimension drawing
Micro hydraulic power units total enclosure, IP68, Micro hydraulic power units total enclosure, IP68,
