Product features
▍ Super Slim, low profile size 145X145mm,
▍ Aluminum housing with hard anodizing.
▍ Low noise level 60dB.
▍ High tolerable to tough working conditions.
▍ Oil-immersed AC motor built-in.
▍ Total enclosure with IP68 protection grade.
▍ Fit in narrow space .
- Drive single acting hydraulic cylinder or actuator.
- Variety of option for special application requirments .
- Pressure Port: 1. G1/4 (BSPP 1/4")，2. NPT 1/8"， 3. M8X1
- Rated Power： Output 650-700W ,
- Voltage: 1) AC 220-240V single phase 50Hz ,2)380V three phase , 3) AC 110V single phase, 60Hz, 4) AC 230V, 60Hz, three Phase
- Duty Cycle: Intermittent, S2=30s, S3 15% ED.
- Max Pressure: 170Bar (2450PSI)
- Proof Pressure: 230 Bar (3335PSI)
